Swift Metric Coilover Springs 8-inch 65mm ID pair
Couldn't load pickup availability
*Images are for reference only, the actual product may vary.
8" Swift Springs are sold in Pairs.
Swift springs for use with most coilover kit's that use 65mm ID springs. These are 8" springs with 65mm Inner diameters. Replace your old worn out springs, or change up spring rates with top shelf Swift springs.
Swift springs are a great way to Improve ride quality and customize your coilovers spring rates. Most coilover brands do not recommend going more than 2-4K higher or lower than original spring rates for the best damper performance. Silver's kits can generally handle a 4k rate difference with no issues.
| 8" LENGTH | ||||||
| PART NUMBER | SPRING RATE | USABLE STROKE | MAX STROKE | |||
| kgf/mm | lbs/inch | mm | Inch | mm | Inch | |
| Z65-203-040 | 4.0 | 224 | 132 | 5.2 | 139 | 5.5 |
| Z65-203-050 | 5.0 | 280 | 126 | 5.0 | 133 | 5.2 |
| Z65-203-060 | 6.0 | 336 | 118 | 4.6 | 131 | 5.1 |
| Z65-203-070 | 7.0 | 392 | 115 | 4.5 | 127 | 5.0 |
| Z65-203-080 | 8.0 | 448 | 107 | 4.2 | 128 | 5.0 |
| Z65-203-090 | 9.0 | 504 | 102 | 4.0 | 128 | 5.0 |
| Z65-203-100 | 10.0 | 560 | 100 | 3.9 | 125 | 4.9 |
| Z65-203-110 | 11.0 | 616 | 92 | 3.6 | 126 | 5.0 |
| Z65-203-120 | 12.0 | 672 | 92 | 3.6 | 125 | 4.9 |
| Z65-203-130 | 13.0 | 728 | 89 | 3.5 | 125 | 4.9 |
| Z65-203-140 | 14.0 | 784 | 87 | 3.4 | 123 | 4.9 |
| Z65-203-160 | 16.0 | 896 | 87 | 3.4 | 116 | 4.6 |
| Z65-203-180 | 18.0 | 1008 | 82 | 3.2 | 118 | 4.6 |
| Z65-203-200 | 20.0 | 1120 | 79 | 3.1 | 118 | 4.7 |
| Z65-203-220 | 22.0 | 1232 | 78 | 3.1 | 109 | 4.3 |
| Z65-203-240 | 24.0 | 1344 | 77 | 3.0 | 109 | 4.3 |
Coilover Spring ID (Inner Diameter) by Brand:
Apexi N1 Suspension - 65mm ID
Bilstein Suspension - 60mm ID
BC Racing Suspension - 65mm ID
B&G suspension - 65mm ID
Broadway Static - 60mm ID
Buddy Club Suspension - 65mm ID
CX Racing Suspension - 65mm ID
CKS suspension - 60mm ID
Cusco Suspension - 65mm ID
D2 Racing Suspension - 65mm ID
DGR Suspension - 65mm ID
Eibach Suspension - 65mm ID
H&R suspension - 65mm ID
HKS suspension - 65mm ID
HSD suspension - 65mm ID
Fortune Auto Suspension - 60mm ID
Feal Suspension - 65mm ID
Function and Form Suspension - 65mm ID
GodSpeed Suspension - 65mm ID
ISC Suspension - 65mm ID
ISR Suspension - 65mm ID
JIC Magic Suspension - 65mm ID
JRZ Suspension - 65mm ID
K Sport Suspension - 65mm ID
KW Suspension - 60mm ID
K-Tuned Suspension - 65mm ID
Megan Suspension - 65mm ID
Ohlins Suspension - 65mm ID
Powered by Max Suspension - 65mm ID
RSR suspension - 65mm ID
Stance Suspension - 65mm ID
Skunk2 Suspension - 65mm ID
ST suspension - 65mm ID
Tanabe Suspension - 65mm ID
Tein Suspension - 70mm ID
Vogtland Suspension - 65mm ID
Yellow Speed Suspension - 65mm ID
